Very useful for generating images for presentations. There is also the ability to take onscreen measurements with a selection of metrology tools.Ī very clever microscope with lots of features.
#SMARTSCOPE DIGITAL MICROSCOPE SOFTWARE#
The inbuilt software features image quality optimisation, image stiching, 3D image generation with multifocus image building. The lenses are mounted onto a motorised XYZ stage which also features a tilt function. It comes with two lenses VH-Z20T which magnifies up to 200 time and the VH-Z100T which magnifies up to 1000 times. This is a state of the art digital microscope from Keyence. This is a useful machine for getting quick metrology results using both laser and optics to check the building accuracy of components assembled in the facility. The machine is fully programmable with a program once and then repeat function.Īll measurement outputs can be saved and dimensions can either be calculated using the machine interface and then exported for use in other software packages. The X, Y and Z measurments has an accuracy resolution of 0.5 microns. The working area is (X)500 mm by (Y) 450 mm. This is a high precision metrology machine which includes the additional Digital Range Sensor laser probe. This is our main wire bonder and is used for all the important wire-bonding jobs, and is particularly vital for large volume production work. Link to the Hesse & Knipps BJ820 webpage. It features a realtime bond quality monitoring system. It has a bonding area of 305 mm x 410 mm with a production bonding speed of up to 7 wires per second with a bonding position accuracy of 1 micron. Loops lengths can be from 70 microns up to 20 mm with programable wire lengths, loop heights and individual loop shapes. Wire bonding layout programs can be created which can then be saved and used for future wire bonding operations.
This is a high speed automatic fine wire wedge bonder currently configured for 25 micron aluminium wire.Īutomatic pattern recognition to aid location of bonding pads allows for fully automatic operation. We have two Hesse & Knipps BondJet 820 automatic wire bonders to allow high volume production alongside R&D work. Hesse & Knipps BondJet 820 automatic wire bonder An ALiBaVa readout system is available for characterization silicon detectors.īelow you will find a description of the equipment that is used in the facility. Testing of electronics, sensors and detector modules is carried out with radioactive sources and TCT measurements in the lab, and with protons irradiations at the MC40. Our main expertise is in providing high-density interconnects and precision assembly of semiconductor based detector systems (application specific read-out chips with wafer-scale sensors) for Particle Physics experiments. It has been designed to specifically work with mobile devices only.The BILPA laboratory area consists of an ISO-14644-1 Class-5 and Class-7 clean room for semiconductor detector system assembly and testing.
The SmartScope iGO is not compatible with PCs or Apple Mac. An existing wireless network or internet connection is NOT required. Please note: iGo creates its own Wi-Fi network. Operational Range: 10 meters from a Wi-Fi connected device (outdoors).Support Protocol: 2.4GHz WiFi IEEE802.11b/g/n.Snapshot Mode: Hardware(device) & Software (App) controllable.Magnification: Up to 200x depending on screen size.
#SMARTSCOPE DIGITAL MICROSCOPE ANDROID#
Devices: Connect 3 devices simultaneously (Any combination of iOS or Android devices).Take pictures and record video on each simultaneously.IGo utilises its own WiFi network to connect up to 3 devices including: Also available are a range of stands for holding the microscope to Ideal for recording live events or still's of plants, animals, rocks or even in exploring owl pellets. Th iGo microscope creates it's own wifi network to be easily shared with pupils and students along with the ability to use 3 devices simultaneously. The iGo wireless handheld digital microscope for use with mobile devices.Īn amazing digital wifi digital microscope with up to 200x magnification powered by 3xAA rechargeable batteries supplied along with mains charger.
